The Horstmann Economy 7 Quartz is an electro-mechanical water heating control designed to maximize savings with Economy 7 tariffs․ It features a 24-hour clock, battery backup, and a manual boost timer for extra hot water during the day․ User-friendly and reliable, it ensures efficient energy use and cost savings․
Overview and Benefits
The Horstmann Economy 7 Quartz is a highly efficient and user-friendly water heating control designed to optimize energy savings with Economy 7 tariffs․ Its primary function is to heat water during off-peak hours, reducing electricity costs while ensuring a steady supply of hot water throughout the day․ One of its standout features is the 24-hour clock, which allows users to set specific times for water heating, aligning with cheaper night-rate electricity․ This ensures that energy consumption is both cost-effective and environmentally friendly․
A key benefit of the Economy 7 Quartz is its simplicity and reliability․ The device is designed to be easy to install and operate, making it accessible to homeowners of all technical skill levels․ Additionally, it includes a manual boost timer, which provides flexibility for those needing extra hot water during the day․ This feature is particularly useful for larger households or situations where hot water demand exceeds the usual supply․
Another significant advantage is its battery backup system, which ensures the clock and settings remain active even during power outages․ This adds a layer of convenience and reliability, preventing the need to reset the device after a power interruption․ Overall, the Horstmann Economy 7 Quartz is a practical and efficient solution for managing water heating costs while maintaining a consistent supply of hot water․
Installation Instructions
Ensure your immersion heater is compatible with the Horstmann Economy 7 Quartz and rated up to 3kW․ Follow the step-by-step guide in the manual for proper installation, ensuring all electrical connections are safe and secure․ Always refer to the provided instructions for accurate setup․
Step-by-Step Guide
Ensure compatibility: Verify that your immersion heater is compatible with the Horstmann Economy 7 Quartz and has a rating of up to 3kW․ This ensures safe and efficient operation․
Prepare for installation: Switch off the power supply to the immersion heater and ensure the system is cool before starting the installation process․
Connect the device: Follow the wiring diagram provided in the manual to connect the Economy 7 Quartz to your immersion heater․ Secure all electrical connections properly․
Set the clock: Use the 24-hour clock dial to program your preferred heating times, taking advantage of off-peak electricity rates during the night․
Test the system: Once installed, turn the power back on and test the device to ensure it operates correctly․ Check that the clock is rotating and the boost timer functions as expected․
Final check: Review all connections and settings to ensure everything is configured correctly for your specific needs and Economy 7 tariff․
Key Features of the Device
The Horstmann Economy 7 Quartz features a 24-hour clock, battery backup for up to 150 hours, and a manual boost timer for extra hot water․ It optimizes energy use with Economy 7 tariffs, ensuring cost savings and efficient water heating control․
24-Hour Clock and Battery Backup
The Horstmann Economy 7 Quartz is equipped with a user-friendly 24-hour clock, allowing precise scheduling of water heating to align with off-peak electricity tariffs․ This feature ensures that water is heated during cheaper night-rate periods, maximizing cost savings․ The device also includes a reliable battery backup system, which guarantees continued operation during power outages․ The battery provides up to 150 hours of runtime, maintaining the clock’s functionality and scheduled heating times․ Once the mains power is restored, the battery automatically recharges, ensuring uninterrupted operation․ This combination of a 24-hour clock and battery backup makes the Economy 7 Quartz an efficient and dependable solution for managing water heating schedules․ The clock’s ability to switch between winter and summer modes further enhances its versatility, adapting to seasonal time changes without requiring manual adjustments․ These features collectively ensure that users can enjoy consistent hot water supply while optimizing their energy consumption and reducing bills․
Operating the Economy 7 Quartz
Operating the Horstmann Economy 7 Quartz is straightforward, with its intuitive 24-hour clock and manual boost timer․ Users can easily set heating schedules to align with Economy 7 tariffs, ensuring energy efficiency and reliability․ The boost function provides an extra hour of heating when needed․
Using the Boost Timer
The Horstmann Economy 7 Quartz features a convenient manual boost timer that allows users to override the standard schedule for an extra hour of heating․ This function is particularly useful for times when additional hot water is needed during the day․ To activate the boost timer, simply press the designated button on the control panel․ The timer will then provide a one-hour heating cycle, independent of the pre-set Economy 7 schedule․ This feature ensures flexibility and meets unexpected hot water demands without altering the main programming․ The boost timer is a key advantage of the Economy 7 Quartz, offering users greater control over their water heating needs․ It is simple to operate and does not interfere with the unit’s ability to utilize off-peak electricity for cost savings․ By combining the boost timer with the 24-hour clock, the device provides both efficiency and convenience, making it an ideal solution for households seeking to manage their energy usage effectively․
Troubleshooting and Maintenance
Regular maintenance ensures optimal performance of the Horstmann Economy 7 Quartz․ Check the battery backup, which lasts up to 150 hours, and ensure the immersion heater is compatible․ Verify the 24-hour clock settings, especially during daylight saving changes, to maintain accurate operation․ Addressing common issues promptly prevents operational disruptions․
Common Issues and Solutions
While the Horstmann Economy 7 Quartz is reliable, users may encounter some issues․ One common problem is the device not turning on, which can be resolved by checking the power supply and ensuring all connections are secure․ Another issue is incorrect time settings, often due to daylight saving changes․ To fix this, manually adjust the 24-hour clock dial to the correct time and mode (summer/winter)․ If the boost timer isn’t functioning, ensure it’s properly set and that the immersion heater is compatible․ Battery backup issues, such as the clock stopping, can be addressed by replacing the battery or ensuring the device is plugged into a working mains supply․ Additionally, if the water isn’t heating, verify that the Economy 7 Quartz is correctly programmed and that the immersion heater is functioning․ Regular maintenance, such as checking the battery and connections, can prevent many of these issues․ Always refer to the manual for detailed troubleshooting steps to ensure optimal performance․
